WTE Series CAN bus inclinometer(ZM)

Woosens WTE series CAN bus inclinometer is a low power consumption and high-performance inclinometer module. And communicate using CAN bus protocol. They are engineered with MEMs devices for reliability and built to withstand rugged applications.

Product details

Power Supply	9~35V
Operating current	20~120mA
Interface	CAN bus
Operating Temperature	-40~85°C
Measuring range	±15°/±30°/±90°/0-360°
Temperature Drift	0.008°/°C (maxium)
Measuring axis	X-Y(360°Measuring range is uniaxial only))
Frequency response	10Hz
Relative accuracy	±15°measuring range ±0.10°
	±30°measuring range ±0.10°
	±90°measuring range ±0.30°
	0-360°measuring range ±0.30°

Power Supply	9~35V
Operating current	20~120mA
Interface	CAN bus
Operating Temperature	-40~85°C
Measuring range	±15°/±30°/±90°/0-360°
Temperature Drift	0.008°/°C (maxium)

Measuring axis	X-Y(360°Measuring range is uniaxial only))
Frequency response	10Hz
Relative accuracy	±15°measuring range ±0.10°
	±30°measuring range ±0.10°
	±90°measuring range ±0.30°
	0-360°measuring range ±0.30°

Collapse

Download

NAME	TYPE	LANGUAGE	SIZE
WTE Series CAN bus inclinometer(ZM)	Datasheet	English

Product characteristics

Woosens WTE series CAN bus inclinometer with two interface modes: CAN bus user-defined protocol and CANopen standard protocol, and incorporates gyroscope compensations to enhance overall resolution, repeatability, and response in medium and heavy dynamic applications. The product has undergone strict production calibration, factory inspection, to ensure excellent product consistency and reliability.

Product application

Material handling equipment
Construction machinery
Agricultural equipment
Forklifts
Cranes
Fire truck
Pump truck
